Permissible weight (kg) :
Overall dimension(mm)length x width x height :
8380X2500X3740
Dump body inside dimension (mm) :
Track (mm) FR/RR :
2060/1855
Overhand (FR/RR) (mm) :
1410/2260
Approach/Departure angle(°) :
Min. ground clearance(mm) :
≥200
Min turning diameter (mm) :
≤16
Power rating (ps)kw/r/min :
(350)259/2100
Max torque (Nm/r/min) :
1454/1100
Rated working volume (m³) :
8
Geometric volume ( m³) :
12.8
Max diameter of drum (mm) :
2246
Front/rear axle :
8/13 tons, double rear axle
Transmission :
RT-11509C/DC12J150T
Clutch :
Dry type single- chip φ430mm Dry type single- chip
Feeding speed ( m³/min) :
≥2.7
Discharging speed ( m³/min) :
≥0.65
Main reducation ratio of rear axle :
4.625
Cab :
Four-points full-floating, electronically controlled hydraulic cab tipping system.
Dump body lifting time(s)(no-load) :
Dump body landing time(s)(no-load) :
