YC5250GJBFS2PM
More
Model :
YC5250GJBFS2PM
Driveline :
6X4
Permissible weight (kg) :
Max. gross weight :
2500
Overall dimension(mm)length x width x height :
8940X2500X3900
Dump body inside dimension (mm) :
Wheelbase :
3640+1410
Track (mm) FR/RR :
2060/1855
Suspension FR/RR (mm) :
Overhand (FR/RR) (mm) :
1410/2480
Approach/Departure angle(°) :
Min. ground clearance(mm) :
≥200
Min turning diameter (mm) :
≤17
Curb weight :
Max.speed（km/h) :
90
Engine model :
PIIC-UJ
Power rating (ps)kw/r/min :
(350)259/2100
Max torque (Nm/r/min） :
1454/1100
Displacement (L) :
10.52
Rated working volume (m³) :
9/10
Geometric volume ( m³) :
15.1/15.3
Max diameter of drum (mm) :
2300
Front/rear axle :
8/13 tons, double rear axle
Transmission :
RT-11509C/DC12J150T
Clutch :
Dry type single- chip φ430mm
Power takeoff :
Feeding speed ( m³/min) :
≥2.7
Discharging speed ( m³/min) :
≥0.65
Main reducation ratio of rear axle :
≥0.65
Tire :
11.00R20
Emission :
Euro III
Cab :
Four-points full-floating, electronically controlled hydraulic cab tipping system.
Dump body lifting time(s)(no-load) :
Dump body landing time(s)(no-load) :
Max.lifting angle(°) :
Note :
