Permissible weight (kg) :
39470
Max. gross weight :
25000
Overall dimension(mm)length x width x height :
6770X2495X3030(3520)
Dump body inside dimension (mm) :
Track (mm) FR/RR :
2060/1855
Suspension FR/RR (mm) :
1410/800
Approach/Departure angle(°) :
Min. ground clearance(mm) :
200
Min turning diameter (mm) :
17
Max.speed（km/h) :
75,90,120
Engine model :
P11C-UJ , P11C-UR
Power rating (ps)kw/r/min :
(350)259/2100 , (380)280/2100
Max torque (Nm/r/min） :
1454/1100 , 1594/1100
Rated working volume (m³) :
Max diameter of drum (mm) :
Front/rear axle :
7000kg/13000kg(two axles)
Transmission :
RT-11509C/DC12J150T , ZF16S1650
Clutch :
single dry plate 430mm
Feeding speed ( m³/min) :
Discharging speed ( m³/min) :
Main reducation ratio of rear axle :
Tire :
11.00-20,11.00R20,295/80R22.5
Cab :
Four-points full-floating, electronically controlled hydraulic cab tipping system
Dump body lifting time(s)(no-load) :
Dump body landing time(s)(no-load) :
