Seats :
23-51
Overall dimension(mm) :
11500×2500×3540
Front/Rear Suspension :
2525/3235/5740
Curb weight(kg) :
11980
Max total weight(kg) :
16000
Parameter :
Max speed(km/h) :
≥120
Max climbing degree(%) :
≥30
Oil consumption(L/100km) :
≤19(Limited condition)
Engine Parameter :
Model :
HINO J08E
Type :
In-line six 、water-cooling 、four-stroke 、electronically controlled 、intercooling ,supercharging diesel
Max Power(Kw/rpm) :
221/2500
Max  Torque(N.m/rpm) :
1000/1500
Chassia Parameter :
Clutch :
HINO hydraulic power steer
Gear box :
ZF Pushi-pull line control
Front/rear axle :
HINO Front/rear axle , Domestic Front/rear axle
Suspension type :
HINO Six gasbag air suspension(Front overhang squat) , Domestic Six gasbag air suspension
Braking system :
Air pressure double loop 、circuit drum
ABS :
WABCO
Retarder :
Eddy current
Steering gear :
Import power steering 、automatic pressure relief
Tyre :
11R22.5-16PR
Wheel rim :
22.5×8.25
Parameter :
Antiseptic art :
Vehicle cathode electrophoresis
Body structure :
Integral
Passenger door :
Pneumatic swing
Baggage volume :
7.6M3/ Manual turn type
Air conditioning and warm wind :
Air conditioning :
Overhead nonfreestanding air conditioning
Air conditioning refrigerating capacity :
28000kCal/h
Warm wind :
Water heating
Interior and service facilities :
Front panel :
Overall reduction glass
Side window :
Surface enclosed 、single light green glass
Interior :
Leather soften type interior
Instrument desk :
Foam vacuum forming ,new dark
Driver seat :
High back of a chair ,adjustable
Passenger seat :
Luxurious passenger seat
Exterior mirror :
New adjustable manual defrost
Roller blind :
Half of that namely pull namely stop type(2)
Back guide monitor :
Device domestic black and white 4.5 inches
Car audio-visual system :
Hard disk player ,the former 17-inche LCD
Inner luggage rack :
Bracket type rack
